NOTE:

The demo bikes that we sell were used for testing and demonstration purposes and may have some signs of wear and tear. They are sold as-is, without warranty, and all sales are final. Thank you for your understanding.

Actual pictures available upon request.

For inquiries, please call us at 805-707-2777.

** Optional External Battery to extend capacity to 990 Wh (Sold separately). Click for Easy Setup Manual.

DESCRIPTION

Get ready to experience the thrill with the Thundra X e-MTB bike designed for urban and cross country riding! The top-end emountain bike with modern geometry, integrated dropout speed sensor, and Xtralite alloy frame is a beauty.

Unleash the power of the Shimano E7000 motor, backed by an integrated 630 Wh battery, both seamlessly concealed inside a durable frame to handle the rigors of mountain bike riding. An optional Simplo 360Wh battery can be attached to the top portion of the downtube for easy extension to 990Wh range. External Battery should be purchased separately.

The compact and lighter engine design and stealth alloy frame help with resistance and mobility for better speed and performance. Stealth Alloy technology uses smartly designed tubes catering to specific functions with the goal of achieving the lowest weight.

High-speed riders will love the safety and confidence offered by Mondraker’s proprietary forward geometry design. Forward geometry also helps with improved handling, overall control, uphill precision, and stability in tough and technical terrains.

Thundra X Ebike sports high-performance rear derailleurs, boost rear axle, integrated dropout speed sensor, and 29” tires, for ultimate precision and grip through uneven and rough trails. Extreme riders can conquer rigorous trails in the comfort of consistent and unstoppable braking power from durable, all-terrain compatible, MTB brakes. Mondraker’s unique high-performance suspension system helps with stability and control by absorbing the strongest vibrations and keeping your wheels planted on the ground even on the bumpiest of the trails.

Riding stats are just a few clicks away on the Shimano Steps E7000 display, with easy wireless connectivity features. Mountain bikers can easily switch between boost, trail, eco, and walk riding modes, making the Thundra X e-MTB bike the perfect choice for off-road adventures.

Sizes: XS: 380mm / S: 390 mm / M: 430mm / L: 470mm / XL: 510mm
Colors: Matte Black / Graphite

SPECS

COMPONENTS / TECHNICAL SPECIFICATIONS

FRAME	Thundra 6061 Xtralite Full Butted Alloy, Forward Geometry, integrated internal non-removablebattery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor.*Optional external battery
SIZES	XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm
REAR SHOCK	-
SHOCK SETTINGS	-
FORK	RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mmaxle, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
HEADSET	Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45°x45°,bottom 51.9x40x8x45°x45°
STEM	MDK Urban 35mm, 6061 forged alloy, 31.8mm barbore
HANDLEBAR	Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9° backsweep, 5° upsweep,31.8mm barbore
GRIPS	Onoff Diamond, 1lock-on, 135mm
SEATPOST	Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
SADDLE	Fizik Terra Aidon X5 145mm
FRONT BRAKE	Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
REAR BRAKE	Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
BRAKE LEVER	Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
RIMS	MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes
SPOKES	CN round stainless steel
FRONT HUB	Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts
REAR HUB	Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts
FRONT TIRE	Maxxis Grifter 29x2.5, single compound, 60TPI, wire bead, tanned wall
REAR TIRE	Maxxis Grifter 29x2.5, single compound, 60TPI, wire bead, tanned wall
CRANKSET	FSA, 165mm
RINGS	Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
BOTTOM BRACKET	-
PEDALS	-
CHAIN	Sram SX Eagle, 12s, Powerlock
FRONT DERAILLEUR	-
REAR DERAILLEUR	Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
SHIFT LEVERS	Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click
CASSETTE	Sram PG-1210, 11-50T, 12s
MOTOR	Shimano STEPS E7000
BATTERY	Simplo internal 630Wh
DISPLAY	Shimano STEPS E5003
DERAILLEUR HANGER	Mondraker M068
OTHERS	Front light: 50LUX output DC 6-12V, waterproof Alloy cage. Rear Light: Fender Mount, w/ Reflective, e-bike version, 6-12V. Fenders: Alloy black MDK custom fenders. Rack: Alloy MDK rear Rack, Max loading 25kg. Kickstand: Massload KSA18-40. *Optional external battery: Simplo 360Wh
WEIGHT	-

GEOMETRY

MEASUREMENTS / GEOMETRY (Click on image to expand)

	Size	XS	S	M	L	XL
A	Seat Tube Length	380 mm	390 mm	430 mm	470 mm	510 mm
B	Top Tube Length	600 mm	615 mm	645 mm	670 mm	700 mm
C	Bottom Bracket Drop	-60 mm	-60 mm	-60 mm	-60 mm	-60 mm
D	Bottom Bracket Height	317 mm	317 mm	317 mm	317 mm	317 mm
E	Chainstay Length	455 mm	455 mm	455 mm	455 mm	455 mm
F	Seat Tube Angle, Actual	73.5°	73.5°	73.5°	73.5°	73.5°
G	Seat Tube Angle, Effective	73.5°	73.5°	73.5°	73.5°	73.5°
H	Head Tube Angle	69°	69°	69°	69°	69°
I	Fork Offset	51 mm	51 mm	51 mm	51 mm	51 mm
J	Wheelbase	1138mm	1153 mm	1183 mm	1210 mm	1240 mm
K	Head Tube Length	110 mm	110 mm	110 mm	130 mm	130 mm
L	Reach	410 mm	425 mm	455 mm	480 mm	505 mm
M	Stack	640 mm	640 mm	640 mm	658 mm	658 mm
